Nema 34 ( 4:1 ) 4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

China Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head supplier

Large Image :  Nema 34 ( 4:1 ) 4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Product Details:

Place of Origin: China
Brand Name: Charmhigh
Certification: CE
Model Number: Nema 34 ( 4:1 ) K12-100mm Chuck 4 jaw

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: $378 Free shipping DHL
Packaging Details: Foarm papaer box
Delivery Time: 1-3 days
Payment Terms: TT; Paypal ; Wester union ;
Supply Ability: 200 per month
Contact Now
Detailed Product Description

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 Steppr motor (4:1)





Specifications for 4th Axis:


Chuck type: K12-100MM 4 jaw centering chuck
The clamping range: positive claw (2~30MM), anti claw (30~80MM)
Center height: 65MM
The output shaft diameter: 20MM
Angle: 0.45 degrees per step
The reduction ratio: 4:1 (5M synchronous belt deceleration mode)
Stepper motor: Nema 34, 4 wires, 4.5A stepper motor (New)
The motor shaft diameter: 14MM
A axis Dimensions: length 210MM*width 210MM*115MM
Gross weight: 10.5kg



Tailstock:
Center Height: 65MM
Stretch distance: 50MM
Weight: 2.1KG



Packing List:

1 pcs -- Nema 34 (4:1) 4th Axis 100mm chuck 4 Jaw
1 pcs -- Tailstock



Here is the video taken by a nice buyer named Alexander Haim from Austria,
please copy the link to watch the vide:
www.youtube.com/watch?v=b_Dnv4IZc2Q





Detail pictures:

Nema 34 stepper motor:



Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head





Stepper motor specifications:

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head

Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head







Nema 34 ( 4:1 )  4 jaw Chuck K12-100mm CNC 4th Axis Kit CNC Dividing Head
