4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

China 4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving supplier

Large Image :  4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

Product Details:

Place of Origin: China
Brand Name: Charmhigh
Certification: CE
Model Number: Advanced CNC 4 Axis CNC6040 3D router

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: $2480 include DHL door to door
Packaging Details: Firm export papar box
Delivery Time: 2-3 days
Payment Terms: T;T; Paypal; Western Union
Supply Ability: 200 per month
Contact Now
Detailed Product Description

CNC USB 3 Axis CNC6040 1.5KW Spindle 2.2KW Invert CNC Router Machine Engraver​  220v / 110v


Description:


Charmhigh CNC6040GS CNC Router is updated from CNC6040GD, its speed 2 time faster than 6040GD, velocity from 1000 update to 2000. The structure of the machine also updated, aluminum frame 2mm thicker than 6040GD, more stonger. It is ball screw with metal nut, longer using time and more precise. It is a desktop controlled machine used for engraving and milling kinds of material such as wood, PCB, PVC, composites, plastics, stone, acrylic, foams, also metal such as aluminum, copper, iron and so on. It is suitable for Industry, Technology Research, Advertising Design, Arts creation, Teaching, Student Project and Hobby Purposes. For processing Building Model Making, PCB, Advertising Signs, Artwork, Crafts, Aircraft Models, RC Model parts,etc. You can creat many beautiful artical using your magic head and hands!

If you want a higher speed one, you can choose CNC6040GS, you can do engraving work at office or home. You can make your own desing throught CAM software (Such as ArtCam or some other software which can generate the G-code), machine controlled by mach 3 software, load your G-code to mach3, then machine start working.



Package list:


•    1× Engraving machine
•    1× Control box (different setting , different drive board)
•    1 x water pump for cooling spindle
•    1 x 1.5kW spinle
•    1 x 2.2KW VFD
•    1× Parallel cable
•    1× Power cable (will supply your country's plug)
•    1× Tool box and tools
•    3× Axis motors
•    1 x Manual
•    1x CD software Mach3 English version (or send online after purchase)



Note:
Machine and tools are full completed set. Ready to use, no need installation.
Each machines are all 100% tested well before ship out.
Please purchase it with confidence.




Specifications for CNC6040GS:



Effective working travel

400(X)mm*600(Y)mm*100(Z)mm

Apperance shape dimension

900x690*520mm

Max.workpiece dimension

<=110mm

Work table dimension

840mm*480mm*20mm

Frame materials

Whole machine 6061 aluminium

Leadscrew

1065 Ball screws updated

Driving units

X axis

1605 Ball screws

Y axis

1605 Ball screws

Z axis

1605 Ball screws

Sliding units

X axis

Dia.20mm optical axis

Y axis

Dia.16mm Support rail

Z axis

Dia.13mm optical axis

Stepping motor type

Nema23 two-phase 3A

Stepper motor driver

0~3.5A  4 axis driver

Principal axis collet

ER11 / 3.175 mm & 6mm

Repeat accuracy

0.03mm

Spindle motor

1.5kw water-cooled spindle motor , 0~24000PRM, frequency 400hz

Engraving speed

300~3000 mm/min (Depending on different material)

Carving Instructions

G-code/.tab /.nc / .ncc/.txt

Communication interface

through parallel connection with desktop computer

Compatible computer

Windows XP

Machine voltage

220v / 110v (Will provide the power cord suitable for your country)

Software

Mach3

Gross weight

73KG (with 4th axis & tailstock)



4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving





Control box parameters:



Operating Voltage

AC110V-AC220V(we also stock USA.UK.EU.AU.plugs and 110V-240V power version for the country all over the world.)

Control unit

3A stepping motor driver plus adjustable spindle speed controller

Computer connection

Desktop palrallel port

Command code

G code

Acceptable software

Mach3,EMC2

Protection

Emergency stop button



Applications:



CNC6040GS CNC router can be used in the production of many different items, such as PCB making, school teaching, door carvings, interior and exterior decorations, wood panels, sign boards, wooden frames, moldings, musical instruments, furniture, metal artwork and so on.



CNC 6040 Adavanced model:


4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving
Note:
Machine and tools are full completed set. Ready to use, no need installation.
Each machines are all 100% tested well before ship out.
Please purchase it with confidence.



Advantages:



1. Mach 3 config: (Velocity is updated from 1000 to 2000)

2. 2 Times faster engraving speed, faster than 6040GD normal version

2. Water-cooling1.5kw spindle + 2.2kw VFD

3. Ball screw with thicker and strong aluminum frame (package total weight 73kg)

4. Z axis efficient work travel " 100mm", maximum work material can reach 120mm

5. Engraving 3D items (4th axis, rotary axis included)



(-Stepper motor updated; controller box updated; - drive board updated; - power supply updated)



4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

Warranty:
The complete machine has a warranty period of 1 year from the time of purchase and lifelong service support as well as a long-term factory price supply. We provide online Q/A and troubleshooting support and technical advice service. Provide one to one after-sale service. Each machine 100% test well then sent out.

Samples:

4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving

4th Axis CNC6040 High Speed Version Desktop CNC Router Machine for 3D Engraving
