Description
SMT PNP Machine: CHMT48VA (29 Feeder 2 Heads + Vision System) Size Of Machine: L 960mm*W 655mm*H 285mm
Stencil Printer: Size 320*440mm Reflow Oven: T-962C
Soldering Area: 2500W / 400*600mm
High Light:

Desktop SMT Production Line

,

PCB Stencil Printing Machine

,

T962C Reflow Oven

CHMT48V SMT Pick and Place Machine / Stencil Printer / Reflow Oven T962C Small SMT Line



(CHARMHIGH) YOUTUBE CHANNEL:
www.youtube.com/channel/UCKRczL5Hywx59M_2SWGJOsA




Small SMT Production line:


1.

Stencil Printer Technical Parameters
Type: Manual
G.W: 13kg
Maximum print Area: 320*440mm
Packing size: L 71cm*W 52cm*H 14cm



2.





Technical Parameter for CHMT48VA Dimension L 960mm*W 705mm*H 335mm
PCB Area 10*10~355*355mm
XY Axis travel 400*460mm
Z axis move range 15mm
Pick and Place head 2pcs
Mounting Speed With vision 3000~4000cph; without vision
6000cph-7000cph (Note: cph means chip per hour)
Working Precision ±0.025mm
Stack 8mm=22 stack; 12mm=4 stack; 16mm=2 stack;
24mm=1 stack; Front IC=12 stack;
User-defined IC tray=20 stack
Vacuum pump 2pcs in-build (mute)
Vision system Up view and down view dual cameras
Computer system inside Linux system inside, very stable, no need external PC
Compatible software Altium designer,Protell99SE,PADS,Kicad,Eagle,Cadint,Cadence Orcad,Cadence Allegro,PROTEUS..etc
Support files .csv file
Touch screen 7’’ (15.6cm*9.3cm) industry touch screen
Support packages 0402,0603,0805,1206,1210,3528,5050, SO-16,SOT-23,SOT-89,TO-252,SOP,QFN, LQFP....different kinds of IC (max size 22*22mm)
Voltage AC 110V/ 220V, 50/60HZ (supply the plug for your country)
Gross weight 73kg (with wooden box packing)



3. T962C Reflow oven parameter:



Brand: PUHUI
Model: T962C
Condition: Brand New From Factory
Soldering Max Area: 60 X 40 cm
Size: 68.4 X 50.4 X 22.5cm
Rated Power:  2500W
Process Period:  1~8 min
Supply: AC110V~ AC220V /50~60HZ



Pictures as follows:



1. Stencil printer Middle size 320*440mm


Desktop SMT Production Line Pick Place , Stencil Printing Machine T962C Reflow Oven PCB Assembly Line 0

2. CHMT48VA Pick and place machine with Vision System

 Desktop SMT Production Line Pick Place , Stencil Printing Machine T962C Reflow Oven PCB Assembly Line 1
Desktop SMT Production Line Pick Place , Stencil Printing Machine T962C Reflow Oven PCB Assembly Line 2


3. Reflow oven T962C  400*600mm  2500w





Desktop SMT Production Line Pick Place , Stencil Printing Machine T962C Reflow Oven PCB Assembly Line 3






Applications industry:

Household appliances industry, Auto electronics industry, Power industry, LED industry, security,instruments and meters industry, communications industry, intelligent control industry, Internet of Things(IOT) industry and military industry, etc.
