CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine

CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine

Large Image :  CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine

Product Details:
Place of Origin: China
Brand Name: Charmhigh
Certification: CE
Model Number: CHMT48VB
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $5200
Packaging Details: wooden box
Delivery Time: 1-3 days
Payment Terms: PayPal, credit card, T/T
Supply Ability: 200 Per month

CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine

Description
Feeder: Letf: 29pcs; Right:29pcs; Front Bulk IC Tray:14pcs; Custom IC Tray:10pcs Placement Head: 2pcs
Nozzles: 4 Types Of Nozzle (Juki) Speed: 3000cph With Vision
Accuracy: 0.025mm PCB Max Size: 345mm(L)×355mm(W); Heighest Componnent: 5mm
High Light:

CHMT48VB SMT Placement Machine

,

Double Side Feeder SMT Pick And Place Machine

,

CHMT48VB SMT Pick And Place Machine

CHMT48VB Double side stack, 58pcs Feeders Charmhigh Benchtop 2 heads

Advanced Pick and Place Machine​, 110v 220V English Version CE Passed



Description:

This CHMT48VB is an update version of CHMT48VA, which included dual side feeders with total 58pcs (left 29pcs + right 29pcs).

The operation system is the same as CHMT48VA and it can install more different kinds of materials, using 502---507 different kinds of Juki nozzles, suitable for 0402,0603,0805-5050, SOP,QFN,LQFP,Diode,Transistor,BGA...etc, which can meet more customers' demand.

Buy it at PayPal, click PayPal link to pay: CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 0



Buy it at online store:

https://www.charmhigh-smt.com/sale-420410-chmt48vb-smt-pick-and-place-machine-charmhigh-2-heads-58-feeders-embedded-linux-system-dual-cameras.htm



Buy it at Aliexpress:

https://www.aliexpress.com/item/32670059454.html?spm=2114.12010612.8148356.1.328a23e9e7TMh1



Model CHM-T48VB
PCB area 10mm*10mm - 355mm*355mm
X Y axis Travel 420*460mm
Z axis moving range 15mm
Placement heads 2pcs
Feeders

Left 29pcs + right 29pcs
8mm=44pcs, 12mm=8pcs, 16mm=4pcs, 24mm=2pcs,
Front IC stack=14pcs, user-defined IC tray

Vision system Dual cameras (up & down cameras)
Drive Closed-loop control stepper servo drive system, make sure never lose step
Z axis self-return detection Yes, prevent nozzles breaking
Pull pin self-return Yes
Leakage of material detection method Vacuum detection, vision detection
Touch screen 7”industry touch screen
Main board Independent research industry main board
System Embedded Linux system
Mounting speed 5000cph (vision off); 3000cph (vision on)
Mounting precision ±0.025mm
Components 0402-5050,SOP,QFN (tape width: 8MM,12MM,16MM,24MM)
Machine dimension L 960mm* W 705mm* H 335mm
Vacuum pump -92KPA (2pcs,build-in, mute type)
External air source No need (machine build-in mute vacuum pump 2pcs)
External PC No
Voltage 220V (110V), 50Hz/60Hz
Net weight 68kg
Gross weight 86kg / 116*80*52cm / 0.62m³



Competitive Advantage:
1. Convenient software, Embedded Linux System of the machine, stable industry main board, independent operation, no need external computer, operation easier and more convenient, learn fast.
2. In-build touch screen, no need external monitor, room saved, more convenient operation, USB mouse supported as well.
3. Top and bottom two vision cameras, correct the position of each components, you can view the vision image from screen for every components.(max component size 22*22mm)
4. It has flexible PCB clamping fixture, suitable for different size of PCB.
5. It supported custom IC tray, IC tray can be fixed on machine table.
6. Two mounting heads with 2pcs Juki Nozzles, Juki nozzle inside magnet, so it can be removed by finger, no need to disassemble with wrench, nozzles rotation angle -180 degree to +180 degree.
7. All-in-one machine, 29pcs feeders included in machine, no need to buy other parts, machine is ready to work.
8. Z axis detection, machine's pull needle automatically return to origin to avoid nozzles broken.

9. Max height component support 5mm.
10. Closed-loop control, X,Y Axis with encoder, not out of step.
11. PCB calibrated by two components position, then rest components will be calibrated automatically.
12. With vacuum detection, with automatic feeding, if one component suck crooked, it will automatically throw it to deposit area, then pick a new one to mount again.

13. With vision detection, camera will auto correction component angle and place on PCB board right place. If heads not picking up components, camera will detect it and go back to pick again, 3 times not picking, machine will alarm and stop, after supply material, then continue working, no need to start over again.

14. Comes with convert tool (PC version), edit work file in computer and load work file into machine by USB port, quick and convenient.
15. Support panelized boards.
16. If you don't have PCB file, you can create a new work file to program in machine directly.

17. Support single step.

18. Support cut tapes/ bulk material/ tube material.


Why choose Charmhigh?
1.Light weight body,occupy small area
2.User friendly interface,no need professional SMT engineer,entry-level device
3.High integrated,no need extra pump or any supporting facility
4.High accuracy and reliability,make up the defection of manual work
5.Low cost,reduce expense to own a professional automatic SMT production line
6.International express with door to door service,3-5 working days delivery
7.Especial for laboratory research and development,samples,to avoid any patents and designs revealment


Standard Accessories for CHMT48VB:
1) Pick and Place Machine CHMT48VB 1
2) Juki nozzle total 4pcs (503, 504, 505, 506 size)
3) 8G USB driver 1
4) Power Cord 1
5) Pull needle 2
6) Coil for pull pin1
7) Camera positioning adjust black board 1
8) Hex wrench 6
9) Tweezers 1
10) Brush 1
11) Pen for touch screen 1
12) Fixture for IC tray 4
13) Grease 1
14) English user manual 1

CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 1

CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 2
Top and Bottom camera, make sure each component place very accurate:
 CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 3
 X Y axis motor with encoder, closed-loop control, make sure not out of steps:
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 4
Custom IC Tray, cut tapes also supported:
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 5
Touch screen control (USB mouse also supported):
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 6
Juki Nozzles, very easy opearation, magnet inside, no need to use wrench to pull down:
CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 7


This machine can place capacitors, Resistors, diode, triode, SOP, QNF, LED very well. Smallest component can place 0402.



PCB maching sample:

CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 8



Kindly note:
The pick and place machine is complete set with all accessories included in the package,
It is all-in-one machine, ready to use!
You can use it when you receive it. Good after-sale tech support, please purchase it with confidence.
Enjoy with your pick and place machine!


Warranty:
The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.
We always provide spare parts of machine, factory reliable direct supply.
We provide online Q/A and troubleshooting support and technical advice service.

Provide one to one after-sale service. Each machine 100% tested well before ship out.
Tech support:
Kimi Mob: 0086 135 106 75756
Skype: kimiliu89
E-mail: kimi@charmhigh-tech.com

Welcome to follow us in YouTube: www.youtube.com/c/KimiLiuCharmhigh/videos



If you want to see more information and videos, please contact us by E-mail.
We will response you at the first time.

 CHMT48VB Double Side Feeder Charmhigh Desktop SMT Pick And Place Machine 9
