High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly

High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly

Large Image :  High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly

Product Details:
Place of Origin: China
Brand Name: Charmhigh
Certification: CE
Model Number: TC06 medium SMT production line
Document: Charmhigh TC06 - Catalog.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $24,000~$30,000
Packaging Details: export plywood box
Delivery Time: 5-7 working days
Payment Terms: T/T
Supply Ability: 50 per month
Contact Now

High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly

Description
Solder Paste Printer: Semi-auto Stencil Printer CHM-3250 Pick N Place Mahcine: Charmhigh TC06 (6 Heads)
Reflow Oven: CHM-PC6635 (6 Zones, Up6+down6, With Rail, With PC) Other Machines: SMT Conveyor 50/ 60cm
Highlight:

SMT reflow oven for PCB assembly

,

High precision CHM-551P reflow oven

,

F830 SMT production line oven

High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly
High-end semi-automatic medium SMT assembly line featuring the 4-head CHM-551P pick and place machine for efficient PCBA manufacturing.
Product Specifications
Attribute Value
Solder paste printer Semi-auto stencil printer 3250
PCB loader Full automatic Mini PCB loader
Pick and place machine Charmhigh TC06 (6 heads)
Reflow oven CHM-PC6635 (6 zones, up6+down6, with rail, with PC)
Other machines SMT conveyor 50 or 60cm
Product Overview
High-end 6-head pick and place machine with exceptional accuracy for medium SMT production. CPK certified with CPK >1.0, supports 01005 components, placement speed of 27,800 components per hour, and accommodates PCB sizes up to 350mm(L) x 300mm(W).
This efficient and reliable SMT solution combines semi-automatic stencil printing, precision component placement, and 6-zone reflow soldering for streamlined PCB production.
Semi-Automatic Medium SMT Production Line Package
  • 3250 Semi-automatic solder paste printer
  • Full-automatic mini PCB loader
  • SMT conveyor 50cm
  • TC06 Charmhigh 6-head pick and place machine
  • SMT conveyor 50cm
  • CHM-PC6635 reflow oven (up6 + down6 temperature zones, automatic rail, PC control)
Compact SMT Line for Quality Assembly
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly 0
Charmhigh TC06 SMT Pick and Place Machine
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly 1
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly 2
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly 3
Split-Type Reflow Oven CHM-PC6635
Split-type design allows easier moving and flexible installation, saving valuable workspace. Features automatic rail system and PC control.
High Precision CHM-551P SMT Production Line F830 Reflow Oven Efficient PCB Assembly 4
Service & Warranty
Complete machine includes 1-year warranty from purchase date with lifetime service support.
  • Factory direct supply with guaranteed spare parts availability
  • Online Q/A and troubleshooting support
  • Technical advice service
  • One-to-one after-sale service
  • Each machine 100% tested before shipment
Technical Support
Kimi Liu: Mob/WhatsApp: +86 135 106 75756
E-mail: kimi@charmhigh-tech.com
Follow us on YouTube
For more information, please contact us by email. We will respond promptly.
