K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router

K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router
K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router

Large Image :  K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router

Product Details:
Place of Origin: China
Brand Name: Charmhigh
Certification: CE
Model Number: K11-100mm 3 jaw Chuck 4th Axis
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: $332 Free shipping DHL
Packaging Details: Foarm papaer box
Delivery Time: 1-3 days
Payment Terms: TT; Paypal ; Wester union ;
Supply Ability: 200 per month

K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router

Description
High Light:

4th Axis CNC Dividing Head

,

Hollow Shaft CNC Dividing Head

,

4th Axis Cnc Router Dividing Head

K11-100mm Chuck 3 jaw CNC 4th Axis Hollow Shaft CNC Dividing Head for CNC Router





Specifications for 4th Axis:



Chunk: K11-100mm 3-jaw chuck
Center height: 65mm
Hollow shaft diameter: 21mm
Total height: 115MM
Angle: 0.3 degrees / step
Reduction ratio: 6:1
Stepper motor: Nema 23 stepper motor
Dimension: 210*168*115mm
Gross weight: 10.5kg



Tailstock:
Center Height: 65MM
Stretch distance: 50MM
Weight: 2.1KG



Packing List:

1 pcs -- 4th Axis 100mm chuck 3 Jaw 6:1
1 pcs -- Tailstock



Here is the video taken by a nice buyer named Alexander Haim from Austria,
please copy the link to watch the vide:
www.youtube.com/watch?v=b_Dnv4IZc2Q





Detail pictures:

K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router 0



K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router 1





Stepper motor specifications:



K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router 2

K11-100mm Chuck 3 Jaw CNC 4th Axis Hollow Shaft CNC Dividing Head For CNC Router 3
